Product Description
Topeak Light gauge steel construction frame meet the international standard, selected the high-quality raw materials, use the advanced technology, professional to produce and custom the light steel materials for construction.
Our technical staff is available to consult with architects and installers regarding specifications, installation tips, and on-site training.
- The Light gauge steel frame for partition system
is mainly used in the household wall, walkway, stairwell and other parts of the building. And the parts will be determined according to different requirements.
With light weight, small bottom area to save building space, easy to lay pipelines, many superior performance. And dry operation, strong structure, faster installation, the material can be reused, can meet the architectural and design of the functional requirements of the partition wall.
The specification are :
-Vertical steel keel: 50mm, 75mm, 100mm, 125mm, 150mm
-Through steel keel : 50mm, 75mm, 100mm, 125mm, 150mm
-Cross steel keel: 38mm
- Topeak light gauge steel frame for Wall decorative
apply to various types of building interior wall decoration, can be directly constructed and installed on all kinds of surface, without any treatment, using the same way of installation the ceiling, the suspender nailed to the wall, and the other end directly through the hole of 38mm steel structure fixed with nuts, the steel cross keel can put on it directly, This build a light steel structue wall with the decorative panels.
- Topeak light gauge steel frame ceiling system
is the best choice for the installation of large ceiling, it is flexible, not only has the effect of heat preservation, heat insulation, sound insulation, sound absorption, but also can increase brightness and beauty.
It can be divided into two types, bearing ceiling and non-bearing ceiling, according to the requirements of whether it needs people to enter the ceiling for maintenance.
The overall rigidity of the bearing ceiling keel is good, can withstand the concentrated load of 80~110kg. When the maintainer enter the ceiling should put the shelves on the main keel. Permanent, frequent, overweight shelves for maintains should be directly install on the structure of the roof. The bearing ceiling is usually use Dia 8mm or above suspender.
Non-bearing ceiling only consider the ceiling itself weight and light lamps, will not bear other loads. It`s usually use Dia 6mm suspender.
- Topeak 38mm catcher steel structure for ceiling
including the suspender and 38mm catcher steel structure and cross steel structure.
The suspender go through the hole of the 38mm catcher steel structure and is secured with a nut.
And then insert the cross steel structure directly into the 38mm catcher steel structure.
