Product Description
1. KQS4-10 production capacity
| NO. | PICTURE | Size(LxWxH) | Pcs/Mould | Pcs/Hour | Pcs/Shift |
| 1 |  | 300x150x100mm | 4 | 960-1440 | 7680-11520 |
| 2 |  | 300x150x100mm | 4 | 960-1440 | 7680-11520 |
2. KQS4-10 forming technical parameters
Dimension of host machine | 1600x1400x2100mm | Host machine power | 7.5KW |
Moulding period | 10-15s | hydraulic force | 16MPa |
Weight of the machine | about 1.6 T | Mixer model | KQ350 |
3.KQ350 mixer
No. | Item | Specification |
01 | Model | JD350 |
02 | Charge volume(L) | 0.35 m3 |
03 | Discharge volume(L) | 0.56 m3 |
04 | Capacity(m3/h) | ≥4m3/h |
05 | Max diameter(pebbles/break stone)mm | 40mm |
06 | power | 7.5 KW |
07 | Machine diameter | 1200mm |
08 | weight | 0.42Ton |
4.Belt conveyor:
Item |
Specifaction |
Length | 6000mm |
Width | 500mm |
Speed (m/min) | 1.25 m/min |
Specification (ton/hour) | 30-40 ton/hour |
power(kw) | 1.1kw |
We are professional brick making machine manufacturer and exporter, company exported more than 90 countries and areas , products passed Europe CE standard .
We have many kind of automatic block machine price from 17000-90000 USD ,also have many semi-automatic block machine price from 850-7800 USD,can surely satisfy your needs , if you are interested about our machine ,welcome to contact :
